Industry-specific (industrial) chiller Position: Home > en > Products > Industry-specific (industrial) chiller >
Coating machine dedicated chiller

Coating machine dedicated chiller

Product Code: 568721397
Specifications: RHT-WD
1.Ergonomic panel, fully automatic control, equipped with precision electric temperature controller, can run smoothly for a long time.
2. Adopting high-efficiency heat transfer heat exchanger, which has the advantages of less cooling loss and easy oil return, and the heat transfer tube will not cause frost cracking.
3. Japan-US imported high-performance compressor, high EER value, low noise and stable operation.


\



Water chiller for water-cooled coating machine-Features

1.Ergonomic panel, fully automatic control, equipped with precision electric temperature controller, can run smoothly for a long time.

2. Adopting high-efficiency heat transfer heat exchanger, which has the advantages of less cooling loss and easy oil return, and the heat transfer tube will not cause frost cracking.

3. Japan-US imported high-performance compressor, high EER value, low noise and stable operation.

4. The product is designed according to the characteristics of industrial applications. It has a built-in low-temperature circulating water pump and a stainless steel freezing water tank, which is extremely convenient to use. All materials in contact with water are made of anti-corrosive materials to effectively prevent rust and corrosion. The microcomputer LED quantity controller has a temperature display. , Set the temperature, automatically adjust the frozen water temperature and compressor delay protection function, select brand-name contactors, relays and other electrical components, equipped with a complete indicator light, switch, operation at a glance, built-in electronic water level indicator and alarm device, low water level automatically Alarm, the operator can grasp the water level of the freezing water tank through the control panel, timely replenishment, unique modular design, each compressor's system is safe and independent, even if one system fails, it will not affect the normal work of other systems .



Special chiller for air-cooled coating machine-Features

1. Free installation of cooling tower, easy to install and convenient to move, suitable for occasions without water tower without installation of water source.

2. Low-noise fan motor, excellent cooling and condensation effect, stable throttling mechanism, and excellent anti-rust treatment.

3.Using European and American high-performance compressors, high EER value, low noise and stable operation.

4. The product is designed according to the characteristics of industrial applications. It has a built-in low-temperature circulating water pump and a stainless steel freezing water tank, which is extremely convenient to use. All materials in contact with water are made of anti-corrosive materials to effectively prevent rust and corrosion. The microcomputer LED quantity controller has a temperature display. , Set the temperature, automatically adjust the frozen water temperature and compressor delay protection function, select brand-name contactors, relays and other electrical components, equipped with a complete indicator light, switch, operation at a glance, built-in electronic water level indicator and alarm device, low water level automatically Alarm, the operator can grasp the water level of the freezing water tank through the control panel, timely replenishment, unique modular design, each compressor's system is safe and independent, even if one system fails, it will not affect the normal work of other systems .





Special water chiller for water-cooled screw coating machine-Features

1. Water-cooled chiller uses horizontal shell-and-tube condenser and shell-and-tube evaporator. It has the characteristics of simple structure, stable heat exchange, long-lasting efficiency, and convenient maintenance. It has been recognized as the most ideal structure for central air-conditioning main units. composition.

2. The unit control system adopts imported PLC program controller, and the man-machine interface is equipped with a large screen touch screen. The interface is simple and elegant, and the operation is intuitive and
simple.

3. The unit has reliable safety protection devices, including: high and low voltage protector, exhaust overheat protector, compressor motor overheat protector, overload current protector, antifreeze temperature protector, water flow protector, emergency stop switch, temperature sensing Fusible plugs, safety valves, etc.





Special chiller for air-cooled screw coating machine-Features

1. The air-cooled condenser is a fin type, which adopts double oil ripple hydrophilic aluminum platinum. It is manufactured by professional heat exchanger processing equipment. It has the advantages of compact structure, small size, light weight, and high heat exchange efficiency. Low speed large leaf axial flow fan can effectively reduce the operating noise and reduce the impact on the surrounding environment.

2. The unit control system adopts imported PLC program controller, and the human-machine world is equipped with a large screen touch screen. The interface is simple and elegant, and the operation is intuitive and simple.

3. The unit has reliable safety protection devices, including: high and low voltage protector, exhaust overheat protector, compressor motor overheat protector, overload current protector, antifreeze temperature protector, water flow protector, emergency stop switch, temperature sensing Fusible plugs, safety valves, etc.


After-sales service:

The warranty period is 12 months, free maintenance during the warranty period, only the material cost fee is charged outside the warranty period, and lifetime maintenance.
